Single stone system

GDM.TETRAGO® gap

2 colours 1 texture 3 formats 2 variants

Product details

Chamfers & Edges

Micro bevel (≤ 2x2 mm)
with concealed spacers/​composite stabilizers

proActive features

50 % concrete recycling material
proCycle
50 % concrete recycling material
13 % infiltration-capable surface area, runoff coefficient ψ = 0.3
proDrain
13 % infiltration-capable surface area, runoff coefficient ψ = 0.3
30 % greenable area, runoff coefficient ψ = 0.2
proDrain 0,2
30 % greenable area, runoff coefficient ψ = 0.2
5 % infiltration-capable surface area, runoff coefficient ψ = 0.25
proDrain 0,25
5 % infiltration-capable surface area, runoff coefficient ψ = 0.25
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
proDrain 0,25
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25

Colours

Formats

Legende

Accessible by car
Heavy duty for occasional use
Heavy duty for regular or frequent use
Micro bevel (≤ 2x2 mm)
50 % concrete recycling material
proCycle
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
proDrain

Jointing stone 30 mm (nativo - unprocessed)

Gray
Length x Width x Height
30.0 x 20.0 x 8.0 cm
Gap
30.0 mm
Weight
155.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
30 % greenable area, runoff coefficient ψ = 0.2
Anthracite
Gray
Length x Width x Height
20.0 x 20.0 x 8.0 cm
Gap
30.0 mm
Weight
155.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
30 % greenable area, runoff coefficient ψ = 0.2
Anthracite
Gray
Length x Width x Height
20.0 x 20.0 x 10.0 cm
Gap
30.0 mm
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
30 % greenable area, runoff coefficient ψ = 0.2

Paving stone (nativo - unprocessed)

Gray
Length x Width x Height
40.0 x 20.0 x 8.0 cm
Gap
8.5 mm
Weight
175.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Anthracite
Gray
Length x Width x Height
30.0 x 20.0 x 8.0 cm
Gap
8.5 mm
Weight
175.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Gray
Length x Width x Height
20.0 x 20.0 x 8.0 cm
Gap
6.0 mm
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
5 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Anthracite
Gray
Length x Width x Height
20.0 x 20.0 x 8.0 cm
Gap
8.5 mm
Weight
175.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Gray
Length x Width x Height
30.0 x 20.0 x 10.0 cm
Gap
8.5 mm
Weight
205.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Gray
Length x Width x Height
20.0 x 20.0 x 10.0 cm
Gap
13.0 mm
Weight
195.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
13 % infiltration-capable surface area, runoff coefficient ψ = 0.3
Gray
Length x Width x Height
20.0 x 20.0 x 10.0 cm
Gap
8.5 mm
Weight
205.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25

Product notes

Particularly high concrete quality thanks to high-strength quartz, granite or basalt aggregates
