Godelmann GDM.GRAN block

Product details

Chamfers & Edges

Bevel (> 3x4 mm)

Product gallery

**GDM.GRAN block** B/L/H: 40/100/25 cm Sandstein-Beige nuanciert

Colours

Normal stone; with tongue and groove Sandstone-Beige nuanced

ferro; stainless steel shot-blasted Sandstone-Beige nuanced

Rough visible surface with circumferential chamfer

Normal stone; with tongue and groove Grey

ferro; stainless steel shot-blasted Grey

Rough visible surface with circumferential chamfer

Formats

Legende

Bevel (> 3x4 mm)

Stützwandsystem (1-seitig) (Normal stone; with tongue and groove)

Starting stone

Length x Width x Höhe

100.0 x 88.0 x 25.0 cm

Weight

517.0 kg / St.

Edge

Starting stone

Length x Width x Höhe

100.0 x 48.0 x 25.0 cm

Weight

288.0 kg / St.

Edge

Starting stone

Length x Width x Höhe

100.0 x 32.0 x 25.0 cm

Weight

188.0 kg / St.

Edge

Starting stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Wall stone

Length x Width x Höhe

100.0 x 88.0 x 25.0 cm

Weight

517.0 kg / St.

Edge

Wall stone

Length x Width x Höhe

100.0 x 48.0 x 25.0 cm

Weight

288.0 kg / St.

Edge

Wall stone

Length x Width x Höhe

100.0 x 32.0 x 25.0 cm

Weight

188.0 kg / St.

Edge

Wall stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Label	Length cm	Width cm	Höhe cm	Weight kg / St.
Starting stone	100.0	88.0	25.0	517.0
Starting stone	100.0	48.0	25.0	288.0
Starting stone	100.0	32.0	25.0	188.0
Starting stone	100.0	24.0	25.0	141.0
Wall stone	100.0	88.0	25.0	517.0
Wall stone	100.0	48.0	25.0	288.0
Wall stone	100.0	32.0	25.0	188.0
Wall stone	100.0	24.0	25.0	141.0

Stützwandsystem (1-seitig) Abdecksteine (ferro; stainless steel shot-blasted)

Covering stone

Length x Width x Höhe

100.0 x 88.0 x 25.0 cm

Weight

517.0 kg / St.

Edge

Covering stone

Length x Width x Höhe

100.0 x 48.0 x 25.0 cm

Weight

288.0 kg / St.

Edge

Covering stone

Length x Width x Höhe

100.0 x 32.0 x 25.0 cm

Weight

188.0 kg / St.

Edge

Covering stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Initial cover stone

Length x Width x Höhe

100.0 x 48.0 x 25.0 cm

Weight

288.0 kg / St.

Edge

Initial cover stone

Length x Width x Höhe

100.0 x 32.0 x 25.0 cm

Weight

188.0 kg / St.

Edge

Initial cover stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Label	Length cm	Width cm	Höhe cm	Weight kg / St.
Covering stone	100.0	88.0	25.0	517.0
Covering stone	100.0	48.0	25.0	288.0
Covering stone	100.0	32.0	25.0	188.0
Covering stone	100.0	24.0	25.0	141.0
Initial cover stone	100.0	48.0	25.0	288.0
Initial cover stone	100.0	32.0	25.0	188.0
Initial cover stone	100.0	24.0	25.0	141.0

freistehende Wand (2-seitig) (Normal stone; with tongue and groove)

Starting stone

Length x Width x Höhe

100.0 x 80.0 x 25.0 cm

Weight

470.0 kg / St.

Edge

Starting stone

Length x Width x Höhe

100.0 x 40.0 x 25.0 cm

Weight

235.0 kg / St.

Edge

Starting stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Wall stone

Length x Width x Höhe

100.0 x 80.0 x 25.0 cm

Weight

470.0 kg / St.

Edge

Wall stone

Length x Width x Höhe

100.0 x 40.0 x 25.0 cm

Weight

235.0 kg / St.

Edge

Wall stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Label	Length cm	Width cm	Höhe cm	Weight kg / St.
Starting stone	100.0	80.0	25.0	470.0
Starting stone	100.0	40.0	25.0	235.0
Starting stone	100.0	24.0	25.0	141.0
Wall stone	100.0	80.0	25.0	470.0
Wall stone	100.0	40.0	25.0	235.0
Wall stone	100.0	24.0	25.0	141.0

freistehende Wand (2-seitig) Abdecksteine (ferro; stainless steel shot-blasted)

Covering stone

Length x Width x Höhe

100.0 x 80.0 x 25.0 cm

Weight

470.0 kg / St.

Edge

Covering stone

Length x Width x Höhe

100.0 x 40.0 x 25.0 cm

Weight

235.0 kg / St.

Edge

Covering stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Initial cover stone

Length x Width x Höhe

100.0 x 80.0 x 25.0 cm

Weight

470.0 kg / St.

Edge

Initial cover stone

Length x Width x Höhe

100.0 x 40.0 x 25.0 cm

Weight

235.0 kg / St.

Edge

Initial cover stone

Length x Width x Höhe

100.0 x 24.0 x 25.0 cm

Weight

141.0 kg / St.

Edge

Label	Length cm	Width cm	Höhe cm	Weight kg / St.
Covering stone	100.0	80.0	25.0	470.0
Covering stone	100.0	40.0	25.0	235.0
Covering stone	100.0	24.0	25.0	141.0
Initial cover stone	100.0	80.0	25.0	470.0
Initial cover stone	100.0	40.0	25.0	235.0
Initial cover stone	100.0	24.0	25.0	141.0

Product notes

More product notes

Features

Rough visible surface with circumferential chamfer
Force-fit and form-fit connection (tongue and groove) as drywall construction
Cover stones blasted on top (ferro) without tongue but with groove
Broken visible surfaces (one or two-sided)

Quality

High dimensional accuracy of the stone heights
made throughout from color-coordinated natural stone chippings and sands with UV-resistant iron oxide paints
Garden design elements made of concrete DIN EN 13198 and BGB-RiNGB
Frost/de-icing salt resistance: ≤ 100 g/m2
CO₂ neutrally produced

Installation instructions

Simple installation using installation pliers and appropriate lifting equipment.
A wall without a corner formation can be erected in a half offset with the starting blocks (75/25 cm).
Starter bricks are crushed to 75/25 cm as wall bricks or cover bricks with a length of 100 cm. Starter blocks are only supplied as a two-piece set with a length of 75 and 25 cm.
Factory parallel cutting of fitting pieces according to on-site dimensions for wall thicknesses up to 48 cm possible.
Heavyweight wall, facing brickwork, retaining wall, free-standing wall or combination possible.
Formats for 90° corners (starting bricks) are available in all wall thicknesses according to the list.
All dimensions given are grid dimensions (incl. joint)! The actual stone dimensions may deviate due to the broken side surfaces (B ± 3 cm; L, H ± 0,5 cm)!
Only remove the feather in the area of the overlap with a hammer or stone chisel.
The function of the positive and non-positive connection using tongue and groove must always be guaranteed over the remaining length of the formats.
